Model | HC600B |
Working Width | 600mm |
Working Thickness | 2-90mm |
Feeding Speed | Frequency alternator |
Feeding Power | 0.75kw |
Applicator Roller Power | 0.75kw*2 |
Doctor Roller Power | 0.37kw*2 |
Heating Power | 3kw |
Total Power | 6kw |
Dimension | 1720*1500*1450mm |
Weight | 1300kg |
1 This machine is mainly used for board type furniture, floor, flush door,handicraft and other surface primers ,The treated paint film surface of the machine is smooth and full. No piles of paint before and after.
2 Conveyor belt, applicator roll. doctor roller adopt imported motor .frequency conversion speed That paint film thickness can be more precise controlled.
3 Applicator roller,doctor roller and scraper can choose different working methods according to different requirements, making the operation more convenient and flexible.
4. This machine can be used for UV, PU, PE, NC and waterborne coatings. The paint can be recycled.
5 Equipped with 5 sets frequency converter or cheese PLC each group can be used alone,processing more accurately.
