Finger Joint Machine HC-150-9E
Finger Joint Machine is used to make to make finger grooves on wood, which can be further combined using glue and pneumatic press
Model | FJL150-9E |
Infeed length | 150-900mm |
Shaping thickness | 20-150mm |
Max shaping width of working table | 590mm |
Pressing thickness | 20-80mm |
Press width | 30-150mm |
Shaper spindle diameter | 50mm |
Shaper spindle speed | 6750r/min |
Hogger spindle diameter | 30mm |
Hogger spindle speed | 2840rpm |
Max pressing length | 6040mm |
Max pressing force | 7500kg |
Shaper spindle power | 15kw*2 |
Hogger power | 5.5kw*2 |
Total conveyor power of shaper | 0.75kw * 2 |
Hydraulic system power for press | 4kw |
Saw blade power for press | 4kw |
Total conveyor power for press | 1.5kw |
Total power for belt conveyor | 1.5kw |
Total power for roller conveyor | 4.5 kw |
Total power for chain conveyor | 2.95kw |
Total power | 65.35kw |
Working air pressure | 6-8 bar |
Wind measure of dust collector | 9000m3/h |
Fixing dimensions | 18000*6000mm |
Advantage:
1. Guide rail of finger joint shaper’s conveyor is japan precision linear guide rail to gurantee the shaping accuracy .
2. The design for finger joint shaper is double blades+tooth-tenon knife assembly to provide high precision.
3. The conveyor table of finger joint shaper adopts German pneumatic hydraulic conveyor system to control bakc and forth ,smoothly,low maintenance,high quality .
4. The second push part of finger joint assembler adopts long+short double pushing board design,by this kind of structure ,it can assemble very short workpiece to reduce the cost .
5. Whole machine is conveniently operated by PLC Central integrated programmable controller.
Packaging :
1.Stretch film and plastic film for humidity.
2.Standard marine export plywood case.
3.Pallet packing.
Shipping:
1.We support maritime and land transport.
2.Shipped in 15-30 working days after payment.
