| Specification | H400 | H500 | H630 |
| Max planing width | 400mm | 500mm | 630mm |
| Max planing thickness | 200mm | 200mm | 200mm |
| Min planing thickness | 8mm | 8mm | 8mm |
| Min planing length | 220mm | 220mm | 220mm |
| Feeding speed | 8-12m/min | 8-12mm | 8-12mm |
| Spindle speed | 4800r/min | 4800r/min | 4800r/min |
| Max planing depth | 5mm | 5mm | 5mm |
| Blade number | 4 | 4mm | 4 |
| Spindle dia. | 105mm | 105mm | 105mm |
| Motor | 5kw | 4kw | 7.5kw |
| Dust outlet dia. | 100mm | 100 | 100mm |
| Overall dimensions | 950*830*1230mm | 950*830*1230mm | 1080*830*1280mm |
| Net weight | 445kg | 476kg | 553kg |
Thicknesser Planer |
Packaging :
1.Stretch film and plastic film for humidity.
2.Standard marine export plywood case.
3.Pallet packing.
Shipping：
1.We support maritime and land transport.
2.Shipped in 15-30 working days after payment.
