Specification | MJ225 | MJ230 |
Max working width | 250mm | 300MM |
Max working thickness | 180mm | 180MM |
Feeding speed | 5-18 | 5-18 |
Sawblade diameter | 300 | 300MM |
Saw spindle speed | 4000r/min | 4000R/MIN |
Up-spindle motor | 22kw | 22KW |
Down-spindle motor | 22kw | 22KW |
Lifting motor | 2.2*2kw | 2.2*2KW |
Overall dimensions | 2800*1100*1600mm | 2800*1100*1600MM |
Advantage:
1. Saw blade spacer is finely grinded for the accuracy up to 0.01mm.
2. Double V-shaped steel guide way unit is made from special material, features precision retentivity and wear resistance.
3. Patented auto lubrication oil-free protection mechanism, ensures major sliding surfaces at a minimum wear abrasion.
4. Three upper rows and one bottom row of anti-kickback fingers to prevent chips and knobs from rebounding and hurting people.
5. Upper pressure mechanism motor-driven elevation for convenient and fast thickness adjustment, improves working efficiency obviously.
6. Both saw spindle and pressure rollers are provided with safety limit devices to avoid machine damage due to the false operation.
7. Machine base, column and saw spindle seat are made from high quality cast iron and have been age treated, features steady , robust and precision retentivity.
8. Saw spindle is made from special material and specially processed for high precision, excellent durability and longer service life.
Packaging :
1.Stretch film and plastic film for humidity.
2.Standard marine export plywood case.
3.Pallet packing.
Shipping:
1.We support maritime and land transport.
2.Shipped in 15-30 working days after payment.
1.What’s the main request for you to suggest me a suitable model?
Max working width is most important.
2.How I can use this machine in other country?
The standard machine from us is full complete machine when before shipping,don’t need to installation when you receive it.
3.different power volt need more cost?long time to make?
Yes ,different power volt need customized, it need about 1 week.
If you have any requirement or question, please fill out the form below that we will reply you within 24 hours.
