wood pallet leg nailing machine

Wood board length800-1350mm
Wood board width80-150mm
Wood board thickness12-20mm
Wood block length80-150mm
Wood block width80-150
Wood block thickness80-100(110)mm
Wood board + wood block thickness≦130mm
Productivity400-600pc/h
Nailing gun3pc MAX CN70
Coil nails3000 nails/coil, max. 57mm length,
Nailing motor power2.25kw
Feeding block motor power0.75kw
Total power3kw
Voltage380v 50hz 3phase (Can customize)
Air pressure8 MPa
Electric componentsSchneider brand
Pneumatic componentsAirtac brand
PLC touch screenSiemens
Machine dimension6m*2.4m*2.4m (L*W*H)
Machine weight2500kg

Wood Pallet Leg Nailing Machine

Advantage:

This machine has two parts, one is feeding part, another is nailing part. This machine nailing wood pallet leg aromatically, it can make 8~10 pcs/min, very high efficiency. Also save the labor cost, this machine just need one worker can operate, manual feeding the blacks, then machine working nailing pallet leg aromatically.


Need to manually feeding wood blocks.

Automatic induction the wood blocks, and automatic feeding wood boards.

Machine is consist of two parts, so there are two control switch, each part can be controlled separately, also the switch of nailing part can control the whole machine.

3pc MAX CN70, high quality and working durable.

Packaging :
1.Stretch film and plastic film for humidity.
2.Standard marine export plywood case.
3.Pallet packing.
Shipping:
1.We support maritime and land transport.
2.Shipped in 15-30 working days after payment.

1) How quick we can get the parts from you?

As long as the problem with parts, we will send you free accessories by express, and you can get in 4~5 days.

2) How much support we can get for problems?

We will do our best to help you solve the problem by phone or video, also  overseas services is available.

3) Manuals and electrical for drawings can made in English?

Of course we can do that in English.

5) What’s the capability of this machine?

This machine can make 400~600 pcs/hour, very high efficiency.

6) If I purchase this machine, what service you can provide?

We can install the machine in you factory until you can operate well, but the cost of overseas service is caused on your side.
